Home > > Multifunctional pile driver

ALL PRODUCTS

Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine

Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine

Inquiry
  • Overview
  • Recommended Products
Products Description
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine manufacture
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine details
Product parameters
Model
HWL400R
Remark
Hammer impact
780J
Joule,we can make more powrful impact as your demand
Pile length
0-4000
mm
Duplex gear pump pressure
20
Mpa
Duplex gear pump displacement
40
ml/r
Hydraulic system pressure
20
Mpa
Main valve flow
120
L/Min
Overall Machine weight
6
T
Diesel engine power
80
KW
Rated Speed
2400
R/min
Starting Voltage
24
V
Rotation angle
360
°
Rotation semi diameter(rotating shaft to Pod distance)
1925
mm
Effective press pile stroke
0.-6000
mm
Dimension(LXWXH)
5600*2150*2800
mm
Track shoe
350
mm
Walking motor total displacement
1575
ml/m
Walking motor rated pressure
18
Mpa
Walking motor output torque
4300
N.M
Walking motor rotate speed
50
r/min
Press Pile Diameter
0-600
mm
Drilling Depth
0-4000
mm
Operating Speed (m/min)
1.5
90s/per pile
Number of impacts / strokes per 1 minute
900
times/min
Maximum length of Piles to be rammed
4
M
Walking speed
5-10
Km/hr
Gradeability
0-35
°
Oil tank capacity
200
L
Hydraulic tank capacity (L)
500
L
Company Profile
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine factory

Engineering Equipment Products

· Full-range Construction Tower Cranes · Intelligent Construction Hoists · Traction-type Construction Hoists · Material Hoists · Intelligent Internal Climbing Concrete Placing Machines · Engineering Robots

Industrial Equipment Products

· Power Intelligent Lifting Equipment · European-style Cranes · Photovoltaic Pile Drivers · Bridge Intelligent Maintenance Robots · Super-sized Intelligent Loading Cranes
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine manufacture
Sichuan Huaxi Trade Co., Ltd. is one of the first enterprises in China to obtain the special equipment manufacturing license of the People's Republic of China. It has a super-large tower crane manufacturing license, an A-level license for installation, transformation, and maintenance, and a first-level qualification for professional contracting of lifting equipment installation projects. It has obtained CE certification, Rhein certification, and many other international and domestic qualifications and honors. It is a leading enterprise in the lifting machinery industry to enter the intelligent transformation, and also an enterprise in the industry with special and new enterprises, two-in-one integration, and 5A-level (the highest level) certification for equipment maintenance and repair services.
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine details
As a national high-tech enterprise, Huaxi Jincheng Construction Machinery has obtained 72 patents, 6 software copyrights, 2 provincial-level construction methods, participated in the preparation of 9 standards at all levels, and won a number of scientific and technological achievement awards, including the Sichuan Provincial Science and Technology Progress Award and the Chengdu Municipal Science and Technology Progress Award. It is also one of the top 10 tower crane manufacturers in China.
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine factory
Underground Trenchless Buried Wire Cable Bolting Rigs Horizontal Directional Drilling Machine supplier
